CUSTOMIZED Plastic Dot Coating Silicone Dot Transfer Coating Machine for Affordable

Large Image : CUSTOMIZED Plastic Dot Coating Silicone Dot Transfer Coating Machine for Affordable

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	GAOQI
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	$46,000.00/sets >=1 sets
Packaging Details:	plastic/silicone dot transfer coating machine <br>standard export container: inner packing type: film <br>external packing type: wooden case
Supply Ability:	30 Set/Sets per Month dot coating machine

Contact Now

CUSTOMIZED Plastic Dot Coating Silicone Dot Transfer Coating Machine for Affordable

Description

Features:	Dot Transfer Coating	Applicable Industries:	Manufacturing Plant
Showroom Location:	None	Video Outgoing-inspection:	Provided
Machinery Test Report:	Provided	Marketing Type:	New Product 2022
Warranty Of Core Components:	1 Year	Core Components:	PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump
Condition:	New	Application:	Knitted And Dotted Gloves
Automatic Grade:	Automatic	Production Capacity:	8-20 M/min
Voltage:	380V 50Hz Three Phase	Power:	108kw
Dimension(LWH):	20150mm2740mm2080mm	Weight:	6000
Warranty:	One Year	After-sales Service Provided:	Engineers Available To Service Machinery Overseas
Color:	CUSTOMIZED	Heating Temp:	100-170 Degree Celsius
Oven Length:	15 M	Local Service Location:	None

Technical working Process:
Anti-deviation feeding cloth-screen dot printing-automatic far infrared needle loading-needle plate stenter electric heating drying-automatic needle removal-air cooling-counting-rewinding.

Brand	GAOQI
Power	380V, 50Hz, three-phase
Oven	12M-25M
Process speed	5-45m/min
Power	120KW
Temperature control	PID automatic
size	23600 2500 2100mm
Cooling mode	air cooling
Dispensing method	round dot plastic

Application:
This machine can be used to print plastic dots and various flower-shaped dots on cotton, chemical fiber, blended, non-woven fabrics and other fabrics. It is used for the production of knitted dot plastic glove fabrics, decorative cloths and carpets, etc., which has a non-slip effect.
