45KW Water Based Glue Laminating Machine for Fabric/ Foam/ Felt Advanced Technology

Name: 45KW Water Based Glue Laminating Machine for Fabric/ Foam/ Felt Advanced Technology
Brand: Jiangsu Gaoqi Machinery Co., Ltd
Price: Negotiable USD
Availability: InStock

All Products

Automatic Laminating Machine
(229)

Dot Coating Machine
(82)

Die Cutting Machine
(29)

Automatic Bronzing Machine
(18)

Carpet Cutting Embossing Machine
(6)

Fabric Inspection Machine
(11)

Fabric Heat Jointing Machine
(2)

Fabric Winding Machine
(7)

Leather Sponge Deodorant Machine
(1)

Certification

I'm Online Chat Now

45KW Water Based Glue Laminating Machine for Fabric/ Foam/ Felt Advanced Technology

Large Image : 45KW Water Based Glue Laminating Machine for Fabric/ Foam/ Felt Advanced Technology

Product Details:

Place of Origin:	Jiangsu, China (Mainland)
Brand Name:	GAOQI
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	$8,900.00 - $19,800.00/sets
Packaging Details:	standard export package
Supply Ability:	60 Set/Sets per Month Water Based Glue Laminating Machine

Contact Now

45KW Water Based Glue Laminating Machine for Fabric/ Foam/ Felt Advanced Technology

Description

Features:	Water Based Glue	Applicable Industries:	Manufacturing Plant
Showroom Location:	None	Video Outgoing-inspection:	Provided
Machinery Test Report:	Provided	Marketing Type:	New Product 2022
Warranty Of Core Components:	1 Year	Core Components:	Gear
Condition:	New	Application:	Couch Making
Automatic Grade:	Automatic	Production Capacity:	60 Sets/Mon
Voltage:	380V/220V/customized	Power:	45KW
Dimension(LWH):	7000mm2400mm2300mm	Weight:	4500
Warranty:	12 Months	Heating Method:	Electrical Heating/Gas Heating
Product Name:	Water Based Glue Laminating Machine	After Warranty Service:	Spare Parts
Local Service Location:	None	Port:	Shanghai Port

Product
Another Name:vertical net belt lamination machine ; Chenille carpet lamination machine; white glue lamination machine; water-based
glue lamination machine;shoe materials lamination machine;latex lamination machine;sponge and leather lamination machine, etc

Features:
1.White latex is used as adhesive and high temp. net belt can make sure laminates into one layer.
2.The automatic rectifying of net belt , ensure the laminated products are neat and flat.
3.Utilizes synchronous control with frequency conversion of operating system.
4.According to the characteristics of different materials, part of the device can be changed to achieve the final required.
5.Special specifications can be customized.

Brand	GAOQI
Power supply	380V, 50Hz, three-phase
Process speed	5-45m/min
Gross Power	About 50KW
Heating method	Electric/heat conduction oil/steam
Effective Width	1600mm / can be customized
Diameter of heating roller	1500mm / 1800mm / 2000mm
Spec. Of heating tube	30pcs*1.5kw=45kw
Roller width	1800-3500mm ( according to materials)
Coating Method	Roll Coating
Demension(LWH)	7300mm2450mm2650mm
Gross Weight	About 4500kg

Application:
Mainly used for gluing coating and laminating of coils and coils or coils and sheets .The raw materials are cashmere, polar fleece, plush, suede, sponge, fabrics, non-woven fabrics, EVA, leather ,silk wadding and so on. The finished products are widely used for garment, shoes and hats, luggage, gloves, leather, automotive interiors, toys, carpet , home textiles , etc.
