1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material

1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material

Large Image :  1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material

Product Details:
Place of Origin: China
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: $8,900.00 - $159,999.00/sets
Packaging Details: Fabric To Fabric / Film Laminating Machine <br>standard export container: inner packing type: film <br>external packing type: wooden case
Supply Ability: 100 Set/Sets per Month Film Laminating Machine
Contact Now

1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material

Description
Applicable Industries: Manufacturing Plant Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2021 Warranty Of Core Components: 1 Year
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump Warranty: 1 Year, 1 Year
After-sales Service Provided: Engineers Available To Service Machinery Overseas, Free Spare Parts, Video Technical Support, Online Support, Field Installation, Commissioning And Training, Field Maintenance And Repair Service Base Material: Non Woven,woven,fabrics,leather,PVC/EVA/SBR/TPU,film,sponge,foam,etc
Function: Gluing And Laminating 2-3 Layers Materials Max Laminating Width: 1200-2200mm / Customized
Machine Roll Width: 1800-2500mm / Customized Heating Method: Conduction Oil / Electric / Gas ; Optional
Brand: GAOQI After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: None Port: Shanghai Port

Product Application

This Fabric Lamination Machine is used for gluing fabric, film and other materials, such as:

Fabric, Nonwoven...

Film (Membrane) such as PU, TPU, PTFE, PE, BOPP, OPP, PET, PVC...

Luggage materials, such as EVA, PVC...

Diving Material, such as SBR, CR...

Main Technical Parameters
Material Width:
1800mm, 2000mm, According to The Maximum Material Width
Drying Roller Diameter:
1500mm, customizable
Drying Roller Width:
According to The Maximum Material Width
Running speed:
Running speed:
Power:
 50 KW
 50 KW
  8500 KGS

Main Features

1)Solvent based glue or PU glue is applicable for the film laminating machine.

2)Glue is transferred evenly to material surface via engraved roller (dot or diamond shape or other shapes). Therefore, laminated materials are soft, waterproof and breathable.

3)The glue quantity is decided by two factors: the distance between the glue roller and the glue scraping blade (pneumatic control) and second, the glue roller mesh you choose for the laminating machine.

4)Special high temperature resistant and antirust Teflon paper on the drying roller surface protects materials' original and unique features and characteristics and prevents the glue from sticking to the roller of the laminating machine.

5)Special film unwinding device and film lining reclaimer are installed on the upper plate, facilitating operation as well as saving space. The glue can be transferred onto film or the other fabric before laminating, more options.

6)Efficient cooling device boosts the lamination effect.

1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 0
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 1
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 2
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 3
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 4
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 5
Related Products
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 6

PUR laminating machine

100% Response Rate

1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 8

Bronzing machine

100% Response Rate

1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 10

Water glue laminating machine

100% Response Rate

Certifications
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 12
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 13
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 14
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 15
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 16
Our Service
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 17

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 18

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
1200-2200mm Max Width Fabric to Foam Film Laminating Machine with Foam Base Material 19
Packaging
Size
40HQ
Weight
4.5 T



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
