Cutting Die Function Hydraulic Swing Arm Cutting Press Machine with 2000KG Weight

Cutting Die Function Hydraulic Swing Arm Cutting Press Machine with 2000KG Weight
Cutting Die Function Hydraulic Swing Arm Cutting Press Machine with 2000KG Weight Cutting Die Function Hydraulic Swing Arm Cutting Press Machine with 2000KG Weight Cutting Die Function Hydraulic Swing Arm Cutting Press Machine with 2000KG Weight Cutting Die Function Hydraulic Swing Arm Cutting Press Machine with 2000KG Weight Cutting Die Function Hydraulic Swing Arm Cutting Press Machine with 2000KG Weight Cutting Die Function Hydraulic Swing Arm Cutting Press Machine with 2000KG Weight

Large Image :  Cutting Die Function Hydraulic Swing Arm Cutting Press Machine with 2000KG Weight

Product Details:
Place of Origin: Jiangsu, China
Brand Name: GAQOI
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: $2,200.00/sets >=1 sets
Packaging Details: wooden package
Contact Now

Cutting Die Function Hydraulic Swing Arm Cutting Press Machine with 2000KG Weight

Description
Condition: New Applicable Industries: Manufacturing Plant
Weight (KG): 2000 Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2022 Warranty Of Core Components: 1 Year
Core Components: Gear Warranty: 1 Year
Product Name: Swing Arm Cutting Press Machine After-sales Service Provided: Engineers Available To Service Machinery Overseas
Cutting Force: 12T, 20T , 25T Color: Customized
Key Word: Swing Arm Cutting Press Machine Usage: Cutting Fabric
Machine Type: Swing Arm Clicker Machine Suitable For Material: Non-metallic Materials
Model: GSB-2C Function: Cutting Die

Product Description

high quality hydraulic swing arm cutting press machine



Usage and features:

This machine is suitable for blanking industrial soft plastic board in cutting-die  ,leather,fiber,cotton & fabric, cardboard and so on.

1.It is equipped with automatic lubricating system, to reduce wear, prolong the service life.
2.Using the electronic delay circuit to control the lower limit position of stroke, high precision, and can improve the quality of shoes, the swing arm from the height of the working table regulating by hand wheel, simple, reliable, convenient.



Technical Specifications:

Model GSB-2C/12 GSB-2C/20 GSB-2C/25
Max. cutting force 120KN 200KN 250KN
Width of swing arm 300*450mm 350*550mm 450*550mm

Stroke adjustment range



5-55mm



5-75mm



5-75mm
Cutting speed 0.10m/s 0.10m/s 0.10m/s
Distance between upper and lower plate 60-140mm 60-150mm 60-150mm
Working table size 900*400mm 1000*500mm 1000*500mm
Motor Power 1.1KW 1.5KW 1.5KW
